Elation Lighting Mini Patend - $749 (Stockton)
make / manufacturer:
Elation
model name / number:
Mini Patend
QR Code Link to This Post
A smaller version of the Patend1200 This fixture uses a scanning
mirror effect on a 360º rotating base. With very smooth slow
movements and incredible fast rotations, the Mini Patend produces fantastic
energetic effects!
It is equipped with 19 Gobos, 19 Dichro-colors, motor focus, high speed shutter and dimmer.
The 150W discharge lamp makes this unit useful for many applications.
Specification Data
DMX 512 Standard
16-Bit Resolution (13 DMX Channels)
Digital Display
Roto head technique without any mechanic stops
Positioning Pan / Tilt 360°
Maximum Head-speed 4 rounds per second
Maximum Tilt-speed 4 rounds per second
Optical System
beam angel
Anti-reflection coated lens
Features & Specs
19 Dichroic colors + white
19 Gobos + open
Shutter
Dimmer
Remote focus
Sound to light function
Music controlled
Stand-alone function
High Speed Shutter
Lamp Source ; Cooling
Included lamp: CDM-150W 6000H/4200k
Optional lamp: HSD-150, 3000hrs
Noiseless and regulated fan
Technical Data
Power Consumption: 300w
AC 115V/60Hz
Fuse: T3.15A GMA
Dimension: 16.5"x 11.5"x 11.5"
425 x 285 x 285mm)
• Weight: 24lbs. (11kg)
